PT. DUTA MAKMUR.. DISTRIBUTOR FLENDER & SIEMENS MOTOR
KOMP PERKANTORAN BUKIT GADING
TEL 021- 29451200 -05...FAX 021- 29451208
EMAIL : [email protected]
PRODUK KAMI , TERDIRI DARI :
1.FLENDER RUBER COUPLING N-EUPEX, DISC COUPLING ARPEX ARS
2.FLENDER GEARMOTOR, GEAR REDUCER
3.FLENDER GEARBOX
4.SIEMENS ELECTRIC AC MOTOR
5.SIEMENS EXPLOSIOON PROOF MOTOR
Electric AC motor LOW VOLTAGE merk Siemens SUDAH banyak dunia industri memakainya sebagai penggerak berbagai aplikasi mesin.
Kami menjual electric motor atau motor dynamo DG SPEC SBB :
- Motor Siemens yang kami jual mulai dari 0.12 kw/0.16 Hp Hingga 250 kW/ 335 HP.
- RPM /Pole tersedia 3000 rp/ 2 pole 1500 rpm/4 pole dan 1000 Rpm 6 pole.
- Tegangan Listrik tersedia 3 Phase 380 V/660 V dan 1 Phase 220 V
- Frequensi 50/60 Hz, Calass F Ip 55
- Mounting tersedia B3/Foot Mouning, B5/Flange dan B35 Foot and Flange.
DINAMO LISTRIK
MOTOR LISTRIK ELECTRIC MOTOR MOTOR AC
SIEMENS ELECTRIC MOTOR TYPE 1LG0 1LG0 series has domestic Siemens motor characteristics as follows: > > > 1.motor design manufacturing is EFF2 energy standard manufacture to Europe. 2.broadband wide presure design, protection grade IP55, class F inslution. 3.motor for matte paint appearance paint, environmental protection and energy saving. 4.all electrial junction box design can ratate 360 degree may be base on customer demand to creat the way in to line. operation ( S1) over a speed range 5. Frame and terminal box material grey cast iron 6. Standard color: stone grey ( RAL 7030) 7 Available in 2, 4, 6 pole variants with efficiency grade 3 according to GB18613, and efficiency class IE1 according to IEC60034-30. 8. Specific would stators supporting multiple 3PH mains supply voltages at 50Hz or 60Hz 9. Frame Size 80mm-355mm 10. Rated power range 0.55kw up to 315kw @ 50Hz 11. Standard mounting types and variations ( IEC60034-7) 12. TEFC with IP55 degree of protection ( IEC 60034-5) . 13. Overload capacity of1.5 times rated output torque for 2 minutes ( IEC 60034-1) 14. Reinforced bearings for increased cantilever forces for FS100-355 as option. 15. V-ring as standard on DE rotor shaft for motor with FS80-FS132, and oil seal as option; Oil seal as standard for motor with FS160 and above. 16. Anti-condensation heater ( space heater) as option 17. Winding protection with PTC and PT100 as option 18. Insulation class F, used according to temperature rise B 19. Flexible cable entry ( Rotatable terminal box) 20. Rotor shaft with closed keyway ( A type key) and NDE shaft extension
